Part# 20104379
Apache's ZipLink belt features a blue carboxilated nitrile roughtop on a polyester monofilament spiral link mesh carcass. The ZipLink design eliminates mechanical lace and replaces time consuming, costly, vulcanized endless splices. Features a longer service life due to no "weak link", elimnating failures common to other splices.
The diamond top profile provides positive grip on steep inclines and declines. Using a simple hand tool this belt can be easily spliced on-site to any length, or supplied with prepared ends for quicker installation. Troughable and easily tracked, this belt is an ideal solution when a tough, endless belt is needed.
SPECIFICATIONS
-
UPC: 725559312670
-
Spec#: 4379
-
Ply: 1
-
Working Tension: 150
-
Color: Tan
-
Compound: Natural SBR
-
Carcass: Plastic Mesh
-
Top Surface: Diamond Top
-
Bottom Surface: Bare
-
Thickness / Overall Gauge: 0.285"
-
Weight (PIW): 0.125
-
Elongation @ 100%: 2%
-
Minimum Pulley: 4"
-
Temperature Range: 0°F to 250°F
-
Oil Resistant: No
-
Clipper®: Not Recommended
-
Alligator ®: Not Recommended
-
Staple: Not Recommended
-
Solid Plate: Not Recommended
-
Flexco® Bolt On: Not Recommended
-
Flexco® Rivet: Not Recommended
-
Endless Splice: ZipLink Splice
